Eagle Vision Pard NV007 Scope Holder Tube Replacement Night Vision Kit

The Tube unit is designed to replace the pard NV007 tube.

The USH-46 go over the scope eye relief then need minimum 20mm maximum 45mm.

This unit can be connect to 99% of the scopes from eye relief outer with dimension of 40mm to 46.5mm and it will find the centre automatically while you are tightening it.

Details

TOTAL length: 69mm

Our pard ring length: 24mm

Made of aluminium.

Package includes:

• 1 x Universal scope holder USH-46
• 1 x pard Adaptor ring PR-007
• 1 x Storage case
• 1 x Silicon grease tube

Please note:

The pard 007 is not included.

Setup instructions

1. Have the 007 & EVC adapter connected, then slip them over the eyebell and tighten almost fully.

2. Digitally zoom-in the 007 to ×3.5, look through it and manipulate the 007 until the reticle on-screen is centred both horizontally and vertically.

3. Now fully tighten the EVC adapter.

…it can still pivot slightly, with the multiple ‘fingers’ of the adjustable collet acting like a slightly malleable ball-joint, for fine-tuning.

4. Now back-off the zoom to 0x and you have a perfectly centred 007/scope setup.

Please note:

This unit will not work on any scopes with shorter ocular less then 25mm between the end of the ocular and the reticle illumination control.
